New GMC Sierra 1500 Finance Specials For June 2026

Starting From $66,100

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2674

Curb Weight - Rear 1937

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9100

Wt Distributing Hitch - Max Tongue Wt. 910

Fifth Wheel Hitch - Max Trailer Wt. 7300

Fifth Wheel Hitch - Max Tongue Wt. 2125

Maximum Trailering Capacity 9400

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAB

Rear Tire Order Code QAB

Spare Tire Order Code QAQ

Front Tire Size 275/60R20

Rear Tire Size 275/60R20

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 22 x 9

Rear Wheel Size 22 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.9

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 17

EPA Fuel Economy Est - City 16

EPA Fuel Economy Est - Hwy 28

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L84

Displacement 5.3L/- TBD -

SAE Net Horsepower @ RPM 355 @ 5600

SAE Net Torque @ RPM 383 @ 4100

Trans Order Code MHS

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 170

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 5.3

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 5

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.49

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.89

Ground Clearance, Rear 7.89

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $53,300

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2674

Curb Weight - Rear 1937

Gross Vehicle Weight Rating Cap 6900

Gross Combined Wt Rating 19000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 13100

Wt Distributing Hitch - Max Tongue Wt. 1310

Fifth Wheel Hitch - Max Trailer Wt. 8500

Fifth Wheel Hitch - Max Tongue Wt. 2125

Maximum Trailering Capacity 13100

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAB

Rear Tire Order Code QAB

Spare Tire Order Code QAQ

Front Tire Size 275/60R20

Rear Tire Size 275/60R20

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.9

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 25

EPA Fuel Economy Est - City 23

EPA Fuel Economy Est - Hwy 28

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.49

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.89

Ground Clearance, Rear 7.89

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $44,200

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2674

Curb Weight - Rear 1937

Gross Vehicle Weight Rating Cap 6900

Gross Combined Wt Rating 14500

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9400

Wt Distributing Hitch - Max Tongue Wt. 940

Fifth Wheel Hitch - Max Trailer Wt. 8700

Fifth Wheel Hitch - Max Tongue Wt. 2175

Maximum Trailering Capacity 9400

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 17 x 8

Rear Wheel Size 17 x 8

Spare Wheel Size 17 x 8

Front Wheel Material Steel

Rear Wheel Material Steel

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 20

EPA Fuel Economy Est - City 18

EPA Fuel Economy Est - Hwy 21

Engine Type Turbocharged Gas I4

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 5.3

Engine Camshaft OHV

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.49

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.89

Ground Clearance, Rear 7.89

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $51,300

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2674

Curb Weight - Rear 1937

Gross Vehicle Weight Rating Cap 6900

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9400

Wt Distributing Hitch - Max Tongue Wt. 940

Fifth Wheel Hitch - Max Trailer Wt. 8500

Fifth Wheel Hitch - Max Tongue Wt. 2125

Maximum Trailering Capacity 11200

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 25

EPA Fuel Economy Est - City 23

EPA Fuel Economy Est - Hwy 28

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 5.3

Engine Camshaft OHV

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.49

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.89

Ground Clearance, Rear 7.89

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $55,100

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2674

Curb Weight - Rear 1937

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9100

Wt Distributing Hitch - Max Tongue Wt. 910

Fifth Wheel Hitch - Max Trailer Wt. 8500

Fifth Wheel Hitch - Max Tongue Wt. 2400

Maximum Trailering Capacity 13100

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QDF

Rear Tire Order Code QDF

Spare Tire Order Code XCQ

Front Tire Size 265/65R18SL

Rear Tire Size 265/65R18SL

Spare Tire Size 265/70R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 18 x 8.5

Rear Wheel Size 18 x 8.5

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 17

EPA Fuel Economy Est - City 16

EPA Fuel Economy Est - Hwy 28

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L84

Displacement 5.3L/- TBD -

SAE Net Horsepower @ RPM 355 @ 5600

SAE Net Torque @ RPM 383 @ 4100

Trans Order Code MHT

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 170

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 5.3

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.49

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.89

Ground Clearance, Rear 7.89

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $50,500

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2682

Curb Weight - Rear 1912

Gross Vehicle Weight Rating Cap 6900

Gross Combined Wt Rating 19000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9300

Wt Distributing Hitch - Max Tongue Wt. 930

Fifth Wheel Hitch - Max Trailer Wt. 8400

Fifth Wheel Hitch - Max Tongue Wt. 2100

Maximum Trailering Capacity 13300

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAB

Rear Tire Order Code QAB

Spare Tire Order Code QAQ

Front Tire Size 275/60R20

Rear Tire Size 275/60R20

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.9

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 25

EPA Fuel Economy Est - City 23

EPA Fuel Economy Est - Hwy 28

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 39.88

Second Leg Room 35.24

Second Shoulder Room 64.88

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.94

Width, Max w/o mirrors 81.24

Height, Overall 75.6

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.87

Ground Clearance, Rear 7.87

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $41,600

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2682

Curb Weight - Rear 1912

Gross Vehicle Weight Rating Cap 6900

Gross Combined Wt Rating 14500

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9100

Wt Distributing Hitch - Max Tongue Wt. 910

Fifth Wheel Hitch - Max Trailer Wt. 8800

Fifth Wheel Hitch - Max Tongue Wt. 2200

Maximum Trailering Capacity 9500

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 17 x 8

Rear Wheel Size 17 x 8

Spare Wheel Size 17 x 8

Front Wheel Material Steel

Rear Wheel Material Steel

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 20

EPA Fuel Economy Est - City 18

EPA Fuel Economy Est - Hwy 21

Engine Type Turbocharged Gas I4

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 5.3

Engine Camshaft OHV

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 39.88

Second Leg Room 35.24

Second Shoulder Room 64.88

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.94

Width, Max w/o mirrors 81.24

Height, Overall 75.6

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.87

Ground Clearance, Rear 7.87

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $48,700

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2682

Curb Weight - Rear 1912

Gross Vehicle Weight Rating Cap 6900

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9500

Wt Distributing Hitch - Max Tongue Wt. 950

Fifth Wheel Hitch - Max Trailer Wt. 8400

Fifth Wheel Hitch - Max Tongue Wt. 2100

Maximum Trailering Capacity 11200

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 25

EPA Fuel Economy Est - City 23

EPA Fuel Economy Est - Hwy 28

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 5.3

Engine Camshaft OHV

Engine Block Type aluminum

Engine Cylinder Count 4

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 39.88

Second Leg Room 35.24

Second Shoulder Room 64.88

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.94

Width, Max w/o mirrors 81.24

Height, Overall 75.6

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.87

Ground Clearance, Rear 7.87

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $38,300

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2613

Curb Weight - Rear 1675

Gross Vehicle Weight Rating Cap 6700

Gross Combined Wt Rating 14000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9000

Wt Distributing Hitch - Max Tongue Wt. 900

Fifth Wheel Hitch - Max Trailer Wt. 8900

Fifth Wheel Hitch - Max Tongue Wt. 2225

Maximum Trailering Capacity 9000

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 17 x 8

Rear Wheel Size 17 x 8

Spare Wheel Size 17 x 8

Front Wheel Material Steel

Rear Wheel Material Steel

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 41

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 20

EPA Fuel Economy Est - City 18

EPA Fuel Economy Est - Hwy 21

Engine Type Turbocharged Gas I4

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 4

Engine Valve Count 4

Passenger Capacity 3

Front Head Room 43.11

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 60.9

Wheelbase 126.49

Length, Overall 210.97

Width, Max w/o mirrors 81.15

Height, Overall 75.7

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.88

Ground Clearance, Rear 7.88

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.62

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $38,500

Destination Charge $2,795

Gross Axle Wt Rating - Front 3700

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2594

Curb Weight - Rear 1763

Gross Vehicle Weight Rating Cap 6800

Gross Combined Wt Rating 14500

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9400

Wt Distributing Hitch - Max Tongue Wt. 940

Fifth Wheel Hitch - Max Trailer Wt. 9300

Fifth Wheel Hitch - Max Tongue Wt. 2325

Maximum Trailering Capacity 9800

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3700

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3700

Axle Capacity - Rear 3800

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 17 x 8

Rear Wheel Size 17 x 8

Spare Wheel Size 17 x 8

Front Wheel Material Steel

Rear Wheel Material Steel

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 44

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 28

Fuel Tank Location - TBD -

Drivetrain Rear Wheel Drive

Fuel Economy Est-Combined 20

EPA Fuel Economy Est - City 18

EPA Fuel Economy Est - Hwy 21

Engine Type Turbocharged Gas I4

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 5.3

Engine Camshaft OHV

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 3

Front Head Room 43.11

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 60.9

Wheelbase 139.56

Length, Overall 229.73

Width, Max w/o mirrors 81.15

Height, Overall 75.6

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.9

Ground Clearance, Rear 7.9

Cargo Box Length @ Floor 98.2

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.62

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 89.1

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $67,000

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2845

Curb Weight - Rear 1981

Gross Vehicle Weight Rating Cap 7200

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 8700

Wt Distributing Hitch - Max Tongue Wt. 870

Fifth Wheel Hitch - Max Trailer Wt. 6700

Fifth Wheel Hitch - Max Tongue Wt. 1675

Maximum Trailering Capacity 9000

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.23

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAE

Rear Tire Order Code QAE

Spare Tire Order Code QAQ

Front Tire Size 275/60R20SL

Rear Tire Size 275/60R20SL

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 18 x 8.5

Rear Wheel Size 18 x 8.5

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 47.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 24

EPA Fuel Economy Est - City 22

EPA Fuel Economy Est - Hwy 26

Engine Type Turbocharged Diesel I6

Fuel System Direct Injection

Engine Order Code LZ0

Displacement 3.0L/- TBD -

SAE Net Horsepower @ RPM 305 @ 3750

SAE Net Torque @ RPM 495 @ 2750

Trans Order Code MQC

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 850

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Passenger Capacity 5

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 64.54

Front Hip Room 60.78

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 64

Second Hip Room 59.24

Wheelbase 147.55

Length, Overall 232.9

Width, Max w/o mirrors 81.24

Height, Overall 78.35

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 11.1

Ground Clearance, Rear 11.1

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $79,600

Destination Charge $2,795

Gross Axle Wt Rating - Front 3950

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2845

Curb Weight - Rear 1981

Gross Vehicle Weight Rating Cap 7300

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 8500

Wt Distributing Hitch - Max Tongue Wt. 850

Fifth Wheel Hitch - Max Trailer Wt. 5200

Fifth Wheel Hitch - Max Tongue Wt. 1300

Maximum Trailering Capacity 8700

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3950

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3950

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.23

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QFL

Rear Tire Order Code QFL

Spare Tire Order Code RHF

Front Tire Size LT275/70R18

Rear Tire Size LT275/70R18

Spare Tire Size LT275/70R18

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 18 x 8

Rear Wheel Size 18 x 8

Spare Wheel Size 18 x 8.5

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Aluminum

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 47.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 19

EPA Fuel Economy Est - City 19

EPA Fuel Economy Est - Hwy 16

Engine Type Turbocharged Diesel I6

Fuel System Direct Injection

Engine Order Code LZ0

Displacement 3.0L/- TBD -

SAE Net Horsepower @ RPM 305 @ 3750

SAE Net Torque @ RPM 495 @ 2750

Trans Order Code MQC

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 850

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 2

Passenger Capacity 5

Front Head Room 39.88

Front Leg Room 44.53

Front Shoulder Room 64.54

Front Hip Room 60.78

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 64

Second Hip Room 59.24

Wheelbase 147.55

Length, Overall 233.96

Width, Max w/o mirrors 81.23

Height, Overall 78.65

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 11.5

Ground Clearance, Rear 11.1

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $69,400

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2845

Curb Weight - Rear 1981

Gross Vehicle Weight Rating Cap 7100

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 8700

Wt Distributing Hitch - Max Tongue Wt. 870

Fifth Wheel Hitch - Max Trailer Wt. 6700

Fifth Wheel Hitch - Max Tongue Wt. 1675

Maximum Trailering Capacity 9200

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.23

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAE

Rear Tire Order Code QAE

Spare Tire Order Code QAQ

Front Tire Size 275/60R20SL

Rear Tire Size 275/60R20SL

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 22 x 9

Rear Wheel Size 22 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.9

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 16

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L84

Displacement 5.3L/- TBD -

SAE Net Horsepower @ RPM 355 @ 5600

SAE Net Torque @ RPM 383 @ 4100

Trans Order Code MHS

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 170

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 6.2

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 5

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.51

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 8.08

Ground Clearance, Rear 8.08

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $84,400

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2845

Curb Weight - Rear 1981

Gross Vehicle Weight Rating Cap 7100

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 8700

Wt Distributing Hitch - Max Tongue Wt. 870

Fifth Wheel Hitch - Max Trailer Wt. 6600

Fifth Wheel Hitch - Max Tongue Wt. 1650

Maximum Trailering Capacity 8900

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.23

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code XCE

Rear Tire Order Code XCE

Spare Tire Order Code QAQ

Front Tire Size 275/50R22SL

Rear Tire Size 275/50R22SL

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 22 x 9

Rear Wheel Size 22 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.9

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 24

EPA Fuel Economy Est - City 22

EPA Fuel Economy Est - Hwy 19

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L87

Displacement 6.2L/- TBD -

SAE Net Horsepower @ RPM 420 @ 5600

SAE Net Torque @ RPM 460 @ 4100

Trans Order Code MHS

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 170

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 6.2

Engine Camshaft OHV

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 5

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.51

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 8.08

Ground Clearance, Rear 8.08

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $56,600

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2845

Curb Weight - Rear 1981

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 19000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 12800

Wt Distributing Hitch - Max Tongue Wt. 1280

Fifth Wheel Hitch - Max Trailer Wt. 8700

Fifth Wheel Hitch - Max Tongue Wt. 2175

Maximum Trailering Capacity 12800

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.42

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAB

Rear Tire Order Code QAB

Spare Tire Order Code QAQ

Front Tire Size 275/60R20

Rear Tire Size 275/60R20

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.9

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 24

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.51

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 8.08

Ground Clearance, Rear 8.08

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $53,600

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2845

Curb Weight - Rear 1981

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 14500

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 8800

Wt Distributing Hitch - Max Tongue Wt. 880

Fifth Wheel Hitch - Max Trailer Wt. 8200

Fifth Wheel Hitch - Max Tongue Wt. 2050

Maximum Trailering Capacity 8800

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.42

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAB

Rear Tire Order Code QAB

Spare Tire Order Code QAQ

Front Tire Size 275/60R20

Rear Tire Size 275/60R20

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.9

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 24

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 2.7

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 4

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.51

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 8.08

Ground Clearance, Rear 8.08

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $47,500

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2845

Curb Weight - Rear 1981

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 14500

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9100

Wt Distributing Hitch - Max Tongue Wt. 910

Fifth Wheel Hitch - Max Trailer Wt. 8200

Fifth Wheel Hitch - Max Tongue Wt. 2050

Maximum Trailering Capacity - TBD -

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.42

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 17 x 8

Rear Wheel Size 17 x 8

Spare Wheel Size 17 x 8

Front Wheel Material Steel

Rear Wheel Material Steel

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18

EPA Fuel Economy Est - City 17

EPA Fuel Economy Est - Hwy 20

Engine Type Turbocharged Gas I4

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 5.3

Engine Camshaft OHV

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.51

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 8.08

Ground Clearance, Rear 8.08

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $54,600

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2845

Curb Weight - Rear 1981

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9200

Wt Distributing Hitch - Max Tongue Wt. 920

Fifth Wheel Hitch - Max Trailer Wt. 8700

Fifth Wheel Hitch - Max Tongue Wt. 2175

Maximum Trailering Capacity 12800

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.42

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 24

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.51

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 8.08

Ground Clearance, Rear 8.08

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $58,200

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2845

Curb Weight - Rear 1981

Gross Vehicle Weight Rating Cap 7100

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 8900

Wt Distributing Hitch - Max Tongue Wt. 890

Fifth Wheel Hitch - Max Trailer Wt. 8400

Fifth Wheel Hitch - Max Tongue Wt. 2100

Maximum Trailering Capacity 13100

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.23

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QDF

Rear Tire Order Code QDF

Spare Tire Order Code XCQ

Front Tire Size 265/65R18SL

Rear Tire Size 265/65R18SL

Spare Tire Size 265/70R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 18 x 8.5

Rear Wheel Size 18 x 8.5

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.3

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 16

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L84

Displacement 5.3L/- TBD -

SAE Net Horsepower @ RPM 355 @ 5600

SAE Net Torque @ RPM 383 @ 4100

Trans Order Code MHT

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 170

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 6.2

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 147.44

Length, Overall 231.92

Width, Max w/o mirrors 81.24

Height, Overall 75.51

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 8.08

Ground Clearance, Rear 8.08

Cargo Box Length @ Floor 69.92

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 62.9

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $67,500

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2927

Curb Weight - Rear 1956

Gross Vehicle Weight Rating Cap 7200

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 8700

Wt Distributing Hitch - Max Tongue Wt. 870

Fifth Wheel Hitch - Max Trailer Wt. 5800

Fifth Wheel Hitch - Max Tongue Wt. 1450

Maximum Trailering Capacity 9000

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.23

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAE

Rear Tire Order Code QAE

Spare Tire Order Code QAQ

Front Tire Size 275/60R20SL

Rear Tire Size 275/60R20SL

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 18 x 8.5

Rear Wheel Size 18 x 8.5

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 50.7

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 24

EPA Fuel Economy Est - City 22

EPA Fuel Economy Est - Hwy 26

Engine Type Turbocharged Diesel I6

Fuel System Direct Injection

Engine Order Code LZ0

Displacement 3.0L/- TBD -

SAE Net Horsepower @ RPM 305 @ 3750

SAE Net Torque @ RPM 495 @ 2750

Trans Order Code MQC

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 850

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Passenger Capacity 5

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 64.54

Front Hip Room 60.78

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 64

Second Hip Room 59.24

Wheelbase 157.04

Length, Overall 242.45

Width, Max w/o mirrors 81.24

Height, Overall 78.24

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 10.97

Ground Clearance, Rear 10.97

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $69,900

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2927

Curb Weight - Rear 1956

Gross Vehicle Weight Rating Cap 7100

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 8700

Wt Distributing Hitch - Max Tongue Wt. 870

Fifth Wheel Hitch - Max Trailer Wt. 6300

Fifth Wheel Hitch - Max Tongue Wt. 1575

Maximum Trailering Capacity 9100

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.23

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAE

Rear Tire Order Code QAE

Spare Tire Order Code QAQ

Front Tire Size 275/60R20SL

Rear Tire Size 275/60R20SL

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 22 x 9

Rear Wheel Size 22 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 50.2

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 16

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L84

Displacement 5.3L/- TBD -

SAE Net Horsepower @ RPM 355 @ 5600

SAE Net Torque @ RPM 383 @ 4100

Trans Order Code MHS

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 170

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 6.2

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 5

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 157

Length, Overall 241.45

Width, Max w/o mirrors 81.24

Height, Overall 75.4

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.97

Ground Clearance, Rear 7.97

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $56,900

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2927

Curb Weight - Rear 1956

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 19000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 12400

Wt Distributing Hitch - Max Tongue Wt. 1240

Fifth Wheel Hitch - Max Trailer Wt. 7700

Fifth Wheel Hitch - Max Tongue Wt. 1925

Maximum Trailering Capacity 12400

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.42

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAB

Rear Tire Order Code QAB

Spare Tire Order Code QAQ

Front Tire Size 275/60R20

Rear Tire Size 275/60R20

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 50.2

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 24

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 157

Length, Overall 241.45

Width, Max w/o mirrors 81.24

Height, Overall 75.4

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.97

Ground Clearance, Rear 7.97

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $47,800

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2927

Curb Weight - Rear 1956

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 14500

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9200

Wt Distributing Hitch - Max Tongue Wt. 920

Fifth Wheel Hitch - Max Trailer Wt. 8800

Fifth Wheel Hitch - Max Tongue Wt. 2200

Maximum Trailering Capacity 9300

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.42

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 17 x 8

Rear Wheel Size 17 x 8

Spare Wheel Size 17 x 8

Front Wheel Material Steel

Rear Wheel Material Steel

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 49.5

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 18

EPA Fuel Economy Est - City 17

EPA Fuel Economy Est - Hwy 20

Engine Type Turbocharged Gas I4

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 5.3

Engine Camshaft OHV

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 157

Length, Overall 241.45

Width, Max w/o mirrors 81.24

Height, Overall 75.4

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.97

Ground Clearance, Rear 7.97

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $54,900

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2927

Curb Weight - Rear 1956

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9100

Wt Distributing Hitch - Max Tongue Wt. 910

Fifth Wheel Hitch - Max Trailer Wt. 7700

Fifth Wheel Hitch - Max Tongue Wt. 1925

Maximum Trailering Capacity 12400

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.42

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QBN

Rear Tire Order Code QBN

Spare Tire Order Code QBR

Front Tire Size 255/70R17

Rear Tire Size 255/70R17

Spare Tire Size 255/70R17

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 49.5

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 24

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 157

Length, Overall 241.45

Width, Max w/o mirrors 81.24

Height, Overall 75.4

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.97

Ground Clearance, Rear 7.97

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $58,900

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2927

Curb Weight - Rear 1956

Gross Vehicle Weight Rating Cap 7100

Gross Combined Wt Rating 15000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 11700

Wt Distributing Hitch - Max Tongue Wt. 1170

Fifth Wheel Hitch - Max Trailer Wt. 7700

Fifth Wheel Hitch - Max Tongue Wt. 1925

Maximum Trailering Capacity 13000

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.23

Axle Ratio (:1) - Rear 3.23

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QDF

Rear Tire Order Code QDF

Spare Tire Order Code XCQ

Front Tire Size 265/65R18SL

Rear Tire Size 265/65R18SL

Spare Tire Size 265/70R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 18 x 8.5

Rear Wheel Size 18 x 8.5

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 49.5

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 16

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L84

Displacement 5.3L/- TBD -

SAE Net Horsepower @ RPM 355 @ 5600

SAE Net Torque @ RPM 383 @ 4100

Trans Order Code MHT

Trans Type 10

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.70

Second Gear Ratio (:1) 2.99

Third Gear Ratio (:1) 2.15

Fourth Gear Ratio (:1) 1.77

Fifth Gear Ratio (:1) 1.52

Sixth Gear Ratio (:1) 1.28

Seventh Gear Ratio (:1) 1.00

Eighth Gear Ratio (:1) 0.85

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 4.87

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 170

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 6.2

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 8

Engine Valve Count 4

Passenger Capacity 6

Front Head Room 43.03

Front Leg Room 44.53

Front Shoulder Room 66.02

Front Hip Room 61.18

Second Head Room 40.12

Second Leg Room 43.4

Second Shoulder Room 65.16

Second Hip Room 60.24

Wheelbase 157

Length, Overall 241.45

Width, Max w/o mirrors 81.24

Height, Overall 75.4

Overhang, Front - TBD -

Overhang, Rear w/o bumper - TBD -

Front Bumper to Back of Cab - TBD -

Cab to Axle - TBD -

Cab to End of Frame - TBD -

Ground to Top of Load Floor - TBD -

Ground to Top of Frame - TBD -

Frame Width, Rear - TBD -

Ground Clearance, Front 7.97

Ground Clearance, Rear 7.97

Cargo Box Length @ Floor 79.44

Cargo Box Width @ Top, Rear - TBD -

Cargo Box Width @ Floor 71.4

Cargo Box Width @ Wheelhousings 50.63

Cargo Box (Area) Height 22.4

Tailgate Width - TBD -

Cargo Volume 71.7

Ext'd Cab Cargo Volume - TBD -

Warranty Note <<< Preliminary 2026 Warranty >>>

Basic Years 3

Basic Miles/km 36,000

Drivetrain Years 5

Drivetrain Miles/km 60,000

Drivetrain Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Corrosion Years 6

Corrosion Miles/km 36,000

Roadside Assistance Years 5

Roadside Assistance Miles/km 60,000

Roadside Assistance Note Sierra TurboMax^TM engines, 3.0L & 6.6L Duramax&reg; Turbo-Diesel engines, and certain commercial, government, and qualified fleet vehicles: 5 years/100,000 miles

Maintenance Note First Visit: 12 Months/12,000 Miles

Starting From $53,800

Destination Charge $2,795

Gross Axle Wt Rating - Front 3800

Gross Axle Wt Rating - Rear 3800

Curb Weight - Front 2878

Curb Weight - Rear 1939

Gross Vehicle Weight Rating Cap 7000

Gross Combined Wt Rating 19000

Dead Weight Hitch - Max Trailer Wt. 5000

Dead Weight Hitch - Max Tongue Wt. 500

Wt Distributing Hitch - Max Trailer Wt. 9000

Wt Distributing Hitch - Max Tongue Wt. 900

Fifth Wheel Hitch - Max Trailer Wt. 8600

Fifth Wheel Hitch - Max Tongue Wt. 2150

Maximum Trailering Capacity 13000

Frame Type Hydroformed

Suspension Type - Front Independent

Suspension Type - Rear Solid Axle

Spring Capacity - Front 3800

Spring Capacity - Rear 3850

Axle Type - Front - TBD -

Axle Type - Rear - TBD -

Axle Capacity - Front 3800

Axle Capacity - Rear 3800

Axle Ratio (:1) - Front 3.42

Axle Ratio (:1) - Rear 3.42

Shock Absorber Diameter - Front - TBD -

Shock Absorber Diameter - Rear - TBD -

Stabilizer Bar Diameter - Front 1.30

Front Tire Order Code QAB

Rear Tire Order Code QAB

Spare Tire Order Code QAQ

Front Tire Size 275/60R20

Rear Tire Size 275/60R20

Spare Tire Size 255/80R17SL

Front Tire Capacity - TBD -

Rear Tire Capacity - TBD -

Spare Tire Capacity - TBD -

Revolutions/Mile @ 45 mph - Front N/A

Revolutions/Mile @ 45 mph - Rear N/A

Revolutions/Mile @ 45 mph - Spare N/A

Front Wheel Size 20 x 9

Rear Wheel Size 20 x 9

Spare Wheel Size 17 x 8

Front Wheel Material Aluminum

Rear Wheel Material Aluminum

Spare Wheel Material Steel

Steering Type Electric Rack & Pinion

Steering Ratio (:1), On Center - TBD -

Steering Ratio (:1), At Lock - TBD -

Turning Diameter - Curb to Curb 46.9

Turning Diameter - Wall to Wall N/A

Brake Type Pwr

Brake ABS System 4-Wheel

Disc - Front (Yes or ) Yes

Disc - Rear (Yes or ) Yes

Front Brake Rotor Diam x Thickness 13 x 1.18

Rear Brake Rotor Diam x Thickness 13.6 x 0.79

Fuel Tank Capacity, Approx 24

Fuel Tank Location - TBD -

Drivetrain Four Wheel Drive

Fuel Economy Est-Combined 24

EPA Fuel Economy Est - City 15

EPA Fuel Economy Est - Hwy 18

Engine Type Gas V8

Fuel System Direct Injection

Engine Order Code L3B

Displacement 2.7L/- TBD -

SAE Net Horsepower @ RPM 310 @ 5600

SAE Net Torque @ RPM 430 @ 3000

Trans Order Code MFC

Trans Type 8

Trans Description Cont. Automatic

First Gear Ratio (:1) 4.56

Second Gear Ratio (:1) 2.97

Third Gear Ratio (:1) 2.08

Fourth Gear Ratio (:1) 1.69

Fifth Gear Ratio (:1) 1.27

Sixth Gear Ratio (:1) 1.00

Seventh Gear Ratio (:1) 0.85

Eighth Gear Ratio (:1) 0.65

Ninth Gear Ratio (:1) 0.69

Tenth Gear Ratio (:1) 0.64

Reverse Ratio (:1) 3.82

Transfer Case Model - TBD -

Transfer Case Gear Ratio (:1), High - TBD -

Transfer Case Gear Ratio (:1), Low - TBD -

Cold Cranking Amps @ 0° F (Primary) 730

Maximum Alternator Capacity (amps) 220

Total Cooling System Capacity - TBD -

Engine Oil Cooler Yes

Engine Displacement Units 3.0

Engine Camshaft DOHC

Engine Block Type aluminum

Engine Cylinder Count 6

Engine Valve Count 4
